Fire retardant aluminum foil glass cloth tape designed to prevent the flammable spray of hot oil which can come in contact with hot surfaces thus causing fires in vessel engine rooms. Fire retardant backing (7um foil / FR glue / 90gsm glass cloth 7×9) is available in tape or sheet format and is coated on one side with a high performance Acrylic adhesive for ease of installation and superior adhesion.

TYPICAL APPLICATIONS:

  • Aluminum foil Glass cloth tape use on bent and flang pipes in areas where maintenance is not a consideration and/or space is limited.
  • Fire retardant aluminum foil glass cloth tape has a pressure sensitive adhesive on the inner side for ease of installation.
  • Fire retardant aluminum foil glass cloth tape is wound around the pipe in a spiral motion using a 50% overlap to ensure good adhesion. Be sure that the foil edges are securely fastened. Ends can be secured with wire or clips if desired.
  • Aluminum foil Glass cloth tape use on straight pipes, valves, exhaust equipment, turbochargers, angled and uneven surfaces and anywhere that insulation is required.
  • Cut the Aluminum foil Glass cloth to size with a utility knife or shears. Wrap around the surface to be insulated, butting the ends together forming a seam.

FEATURES:

  • High tensile strength, glass cloth reinforced foil tape offers puncture, fracture and tear resistance.
  • Performs continuously over a wide temperature range from -30℃ to +120℃,-22℉ to +248℉.
  • Light and flexible construction easily conforms to curved or irregular surfaces.
  • Thermally conductive and reflective backing assists with heat shielding.

TYPICAL PHYSICAL PROPERTIES:

PROPERTIES

METRIC

ENGLISH

TEST METHOD

Backing Thickness

120 Micron

4.8Mil

PSTC-133 / ASTM D 3652

Total Thickness

170 Micron

6.8 Mil

PSTC-133 / ASTM D 3652

Adhesion to Steel

18N/25mm

64.8Oz./In.

PSTC-101 / ASTM D 3330

Tack Rolling Ball

15cm

6.0 In.

PSTC-6 / ASTM D 3121

Tensile Strength

255 N/25mm

58.0Lb/In

PSTC-131 / ASTM D 3759

Elongation

5.0%

5.0%

PSTC-131 / ASTM D 3759

Service Temperature

-30℃ to +120℃

-22℉ to +248℉



Fire Rating

Class O & 25 / 50

Class O & 25 / 50

BS476 Pt.6 & 7 / UL 723

ROLL SIZE:

Finish Roll:

50mm x 50m 2” x 55yds
75mm x 50m 3” x 55yds

Log Roll:   1200mm x 50m

Jumbo Roll: 1200mm x 900m
