TPE Expansion Joint Tape

Features & Benefits

• • Integrated Linear Waterproofing: the retractable lap design forms seamless linear connections across joints, realizing full-system waterproofing and eliminating hidden water leakage risks at splicing positions. It ensures the overall waterproof integrity of the entire engineering structure.
  • Permanent Low-Temperature Flexibility: the TPE raw material endows the tape with lasting softness and elasticity. It will not harden, crack or lose sealing performance even in low-temperature environments, suitable for use in cold regions all year round.
  • Excellent UV & Aging Resistance: formulated with anti-aging and UV-resistant components, the tape can withstand long-term outdoor sunlight exposure, rain and wind erosion. It resists aging, fading and performance degradation, extending the service life of the waterproof layer.
• • Acid & Alkali Resistant Polyester Fiber Base: the reinforced polyester fiber layer enhances tensile strength and structural stability. It features good acid and alkali resistance, adapting to complex underground, hydraulic and construction environments with corrosive media.
  • High Elasticity & Displacement Adaptability: superior stretch performance allows the tape to follow large-scale movement of expansion joints, avoiding tearing or detachment caused by structural displacement, vibration or temperature changes.
  • Customization Support: we provide customized colors to match different project design requirements, with standardized specifications and flexible order solutions to meet diverse engineering demands.

• Technical Specifications

  Item	Technical Data
  Product Name	Flexible TPE Expansion Joint Tape
  Main Material	Thermoplastic Elastomer (TPE) + Polyester Non-woven Fabric + Polyester Fiber
  Standard Size	120mm x 50M/Roll, 120mm x 10M/Roll
  Thickness	1.2±0.2mm
  Density	1.0±0.1g/cm³
  Hardness	50±10
  Regular Colors	Black, Blue, Violet (Custom colors available)

  All products are strictly inspected before delivery to ensure every roll of tape complies with the above technical standards and engineering application requirements.



• Tape Applications

  This multi-functional waterproof sealing tape is tailor-made for movable expansion joints and structural cracks, covering multiple industries and engineering fields:

  • Large Displacement Expansion Joints
    Flexible waterproof sealing for joints with frequent and large-range movement in various buildings and infrastructure.
  • Tunnel & Road Engineering
    Waterproof sealing for expansion joints in highway, urban road and tunnel projects, resisting vehicle vibration and pavement deformation.
  • Prefabricated Panel Joints
    Sealing gaps and expansion joints between precast concrete panels for residential, commercial and industrial buildings.
  • Building Façade Structural Joints
    Flexible sealing for external wall structural joints, preventing rainwater from penetrating into the building interior.
  • Hydraulic Engineering
    Sealing joints for water channels, water basins, drainage ditches, water pipes and other hydraulic facilities, adapting to long-term water immersion environments.
  • Flat Roof & Covering Layers
    Waterproof treatment for expansion joints on flat roof covering layers to solve roof leakage problems caused by temperature changes.

  It is applicable to residential buildings, commercial complexes, municipal roads, traffic tunnels, water conservancy projects and other large-scale construction projects, with strong versatility and high engineering practicability.

FAQ:

Q1: Is TPE expansion joint tape completely waterproof?
A1: Yes. Our TPE expansion joint tape is specially developed for joint waterproofing. The composite structure of TPE and polyester fabric forms a continuous waterproof layer, which can effectively block water infiltration and meet the waterproof requirements of various engineering joints.

Q2: Can it be used in cold areas?
A2: Absolutely. The product maintains permanent flexibility at low temperatures, will not harden or crack in cold environments, and is suitable for long-term use in low-temperature regions.

Q3: What colors can be customized?
A3: The regular colors are blue and violet. We can customize various conventional and special colors according to customer samples or color numbers.

Q4: What is the minimum order quantity?
A4: The MOQ for standard products is 200 rolls. For customized products, please contact our sales team to negotiate the order quantity.

Q5: What engineering projects is this tape mainly suitable for?
A5: It is widely used for expansion joint sealing in roads, tunnels, precast buildings, hydraulic pipelines, water tanks, drainage systems and flat roof layers.
