Adhesive aluminum foil tape are single-faced adhesive tapes of thickness 125um aluminum foil backing which is coated by solvent scrylic adhesive. Aluminum foil tape is industrially manufactured, and thus can be manipulated based on the selection of the monomers used in the formulation.

Offer good tack and adhesion to width range of temperature (from -30 degrees to 150 degrees ). Offers reliable and durable Foil-Scrim-Kraft Facing joints and seams sealing in HVAC ductwork application.

Good aging stability, high resistance to UV, ozone and humidity, best useful in long-term, outdoor applications.It resists most conditions including extreme temperatures, humidity, chemicals and UV degradation.

AF-Alum. Foil backing

A-Acrylic adhesive

125-Backing thickness125um

175-Tape thickness175um

TAPE APPLICATIONS:

Adhesive aluminum foil tape designed to seal gaps in ducting to prevent moisture from leaking in and emissions from seeping out.

TAPE FEATURES:

Aluminum backing provides excellent reflection of both heat and light.

High quality adhesive with super strong adhesion and holding power.

Low moisture vapor transmission rate makes AFA125175 an excellent vapor barrier.

Service Temperature range from -30℃ to +150℃.

TYPICAL PHYSICAL PROPERTIES:

PROPERTIES

METRIC

ENGLISH

TEST METHOD

Backing Thickness

125Micron

5.0Mil

PSTC-133 / ASTM D 3652

Total Thickness

175Micron

7.0Mil

PSTC-133 / ASTM D 3652

Adhesion to Steel

20N/25mm

34.0

PSTC-101 / ASTM D 3330

Tensile Strength

150N/25mm

28.5Lb/In

PSTC-131 / ASTM D 3759

Elongation

3.0%

3.0%

PSTC-131 / ASTM D 3759

Service Temperature

-30℃ to +150℃

-22℉ to +302℉



Applying Temperature

-10℃ to +40℃

+50℉ to +105℉



ROLL SIZE:

Finish Roll:

50mm x 50m 2” x 55yds
75mm x 50m 3” x 55yds
Log Roll: 1020mm x 50m
Jumbo Roll: 1020mm x 3000m
