Foil-Scrim-PE Tape

• Tape Description

  Where standard aluminum tapes are prone to accidental punctures, creasing, and tearing under tension, our Foil-Scrim-PE Tape provides structural ruggedness. The embedded Foil PE Mesh Tape matrix distributes mechanical stress evenly, halting rips before they can spread. This structural reinforcement makes it the premier choice for sealing high-tension joints on faced fiberglass blankets, mineral wool insulation, and rigid duct boards.

  The choice of specialized adhesives allows this tape to excel under rigorous field conditions. When configured with our long-life acrylic pressure-sensitive adhesive, the tape maintains its structural bond across broad temperature fluctuations. It actively blocks air leakage, stops moisture vapor transmission, and resists UV degradation. The result is an ultra-durable, energy-efficient vapor seal that shields the underlying thermal insulation core from moisture infiltration and thermal loss.

• Features & Benefits

  • Puncture & Tear-Resistant Matrix: The heavy-duty heat-sealed PE scrim reinforcement prevents tearing and resists punctures from sharp tools or rough handling on-site.
  • Complete Vapor & Moisture Shield: Acts as an impenetrable barrier against water vapor, air leaks, and humidity, keeping insulation completely dry.
  • Broad Temperature & UV Resilience: Engineered with advanced acrylic adhesive that handles severe hot and sub-zero cold cycles without lifting or drying out.
  • Highly Flexible & Conformable: Despite its multi-layer strength, the tape remains flexible enough to conform cleanly around pipe elbows, irregular fittings, and corrugated metal seams.
  • Reflective Energy Efficiency: The polished aluminum outer facing reflects radiant heat, lowering energy consumption in both hot and cold air distribution networks.
  • Clean, Efficient Handling: Supplied with a premium silicone-coated paper liner that peels away smoothly for fast, error-free applications.

Applications

• • HVAC Industry Sealing: Splicing and sealing seams on fiberglass duct boards, mineral wool insulation, and sheet metal pipe sections.
  • Cold Storage & Refrigeration: Sealing joints in commercial walk-in freezers, cold rooms, and refrigerated transit units to stop frost and moisture buildup.
  • Pipe & Conduit Insulation: Wrapping and securing pipe insulation blankets to prevent ambient heat transfer and control condensation.
  • Vapor Barrier Splicing: Patching, repairing, and joining reinforced aluminum foil faced insulation systems in industrial structures.

• Tape Properties

  Foil Scrim PE Tape

  	Backing	Adhesive	Thickness Micron	Backing thickness	Adhesion N/25mm	Tensile N/25mm	Elongation %	Service Temp°C
  FSE18125B/CW	Foil Scrim PE	Solvent acrylic	90	45	22	80	3	–30 ~ 120
  FSE18205BHK	Foil Scrim PE	Rubber-resin	220	150	28	90	3	–20 ~ 80

  Foil PE Mesh Tape

  FEM7105AH	Foil PE mesh	Rubber-resin	200	125	25	100	25	-20 ~ +80
  FEM7125A	Foil PE mesh	Solvent acrylic	175	125	20	100	25	–30 ~ 120

• Tape Roll Size

  Finish Roll:

  50mm x 50m	2” x 55yds
  75mm x 50m	3” x 55yds

  Log Roll:1200mm x 50m
  Jumbo Roll:1200mm x 900m

FAQ:

Q1: What is the main advantage of Foil-Scrim-PE Tape compared to standard foil tape?
A: Standard foil tape tears easily when pulled around corners or subjected to structural shifting. Our Foil PE Mesh Tape includes an integrated polyethylene mesh grid that provides high tensile strength, making it virtually puncture-proof and tear-resistant while maintaining a flexible profile.

Q2: Can this tape withstand long-term outdoor exposure?
A: Yes. The combination of an aluminum foil outer backing and a high-stability PE scrim naturally resists UV degradation, weather exposure, and moisture, ensuring long-term seal integrity in outdoor or unconditioned environments.

Q3: Which adhesive option should I choose for my project?
A: Our high-performance rubber-resin adhesive offers an aggressive, instant grip that is ideal for fast-paced indoor installation at standard ambient temperatures. For applications exposed to extreme temperature swings, high humidity, or long-term outdoor weathering, our solvent-acrylic adhesive is recommended for its durability.

Q4: How do I ensure an airtight vapor seal over rough insulation facings?
A: First, ensure the target substrate is clean, dry, and free of dust, grease, or condensation. Apply the tape over the seam, then use a plastic squeegee or firm hand pressure to smooth out the tape from the center outward. This activates the pressure-sensitive adhesive and molds the reinforced backing completely into the surface texture.
