Vapor barrier & insulation DPTF-1251 is an excellent vapor barrier & reflective insulation. It consists of 12μpolyester film/25 μ aluminum foil/12 μ polyester film. Used as a facing over insulation board, segments, pipe section, etc.

Reflective aluminum foil insulation radiant barriers are installed outside the Glass wool, Rock wool, mineral wool, foam insulation materials.Primarily used in cold/cryogenic insulation systems, to prevent the ingress of moisture into the insulation.Primarily used in cold/cryogenic insulation systems, to prevent the ingress of moisture into the insulation.

Vapor barrier & insulation DPTF-1251 combines the excellent vapor barrier properties of aluminum with the outstanding mechanical and thermal characteristic of polyester film, giving a ideal, flexible and efficient barrier material, suitable for outdoor use.

FACING COMPOSITION:

Composition

Description

Value (English)

Value (Metric)

Film

Polyester

0.5 mil

12 micron

Adhesive

Polyurethane





Foil

Aluminum

1.0 mil

25micron

Adhesive

Polyurethane





Film

Polyester

0.5Mil

12micron

Remarks:

  • The data above are typical values only, and should not be used for specifications purpose.
  • Tolerance: Weight and Thickness: ±10%;Width:±3mm; Length: Log Roll: ±3m, Jumbo Roll: ±0.5%.
  • The products should be stored at room temperature, kept away from wet and heat source.
  • The users should take test and do trial-application on the above products before coming into application so as to witness and ensure suitability for their special purpose and technique.

FACING PROPERTIES:

Physical properties

Test Method

Value (English)

Value (Metric)

Basis weight

Scale

21.7Ibs/1000ft2

106gsm

Permeance (WVTR)

ASTM E96,

Procedure A

0.01perm

0.6 ng/N.s

Tensile Strength-MD

ASTM D828

34 lbs / In

150 N/25mm

Tensile Strength-XD

ASTM D828

27lbs / In

120 N/25mm

Burst Strength

ASTM D774

108psi

75 N/cm2

Low temperature

Resistance

ASTM D1790

4 hrs @

-40℉ (-40℃)

Remains Flexible

No Delamination

Remains Flexible

No Delamination

High temperature

Resistance

ASTM D1790

4 hrs @

+240℉ (+116℃)

Remains Flexible

No Delamination

Remains Flexible

No Delamination

Emissivity

ASTM E408

0.03

0.03



Available Roll Width: 1.20m, 1.35m
