HVAC Aluminum Tape without scrim reinforced backing is a commercial grade foil tape. AFA Series aluminum foil tape are single-faced adhesive tape of aluminum foil backing which is coated by PSA. Suitable for sealing joints and seams of foil-faced insulation materials.
HVAC Aluminum Tape is industrially manufactured, and thus can be manipulated based on the selection of the monomers used in the formulation. AFA aluminum foil tapes will be offer good tack and adhesion to width range of temperature (from -30 degrees to 150 degrees ).
Acrylic adhesive HVAC Aluminum Tape will be good aging stability, high resistance to UV, ozone and humidity, best useful in long-term, outdoor applications.
AF-Alum. Foil backing
A-Acrylic adhesive
50-Backing thickness50um
90-Tape thickness90um
AFA5090 aluminum foil tape is most commonly used to exposed surfaces of Duct wrap, HVAC ductwork, Pipeline insulation. It also used for Exterior wall insulation, Metal building insulation, Hot water tank insulation.
Aluminum backing provides excellent reflection of both heat and light.
High quality adhesive with super strong adhesion and holding power offers reliable and durable Foil-Scrim-Kraft Facing joints and seams sealing in HVAC ductwork application.
Low moisture vapor transmission rate makes AFA5090 an excellent vapor barrier.
Service Temperature range from -30℃ to +150℃.
PROPERTIES |
METRIC |
ENGLISH |
TEST METHOD |
Backing Thickness |
50Micron |
2.0Mil |
PSTC-133 / ASTM D 3652 |
Total Thickness |
90Micron |
3.6Mil |
PSTC-133 / ASTM D 3652 |
Adhesion to Steel |
20N/25mm |
72Oz./In. |
PSTC-101 / ASTM D 3330 |
Tensile Strength |
75 N/25mm |
17.0Lb/In |
PSTC-131 / ASTM D 3759 |
Elongation |
3.0% |
3.0% |
PSTC-131 / ASTM D 3759 |
Service Temperature |
-30℃ to +150℃ |
-22℉ to +302℉ |
|
Applying Temperature |
-10℃ to +40℃ |
+50℉ to +105℉ |
|
Finish Roll:
50mm x 50m | 2” x 55yds |
75mm x 50m | 3” x 55yds |
Log Roll: | 1020mm x 50m |
Jumbo Roll: | 1020mm x 3000m |
